I-39
P
RODUCTS
❈ When the actual capacity of indoor unit is lower than the load, it is recommended to reselect the one with a larger
capacity. But it is ultimately depend on DVM designer’s own discretion.
❈ In other words, if the actual capacity of indoor units is not greatly lower than the load or it is rather rare to simultaneously
operate indoor, the capacity of indoor unit can sufficiently meet cooling and heating load.
6) Comparison between the actual capacity of each indoor unit & cooling and heating load
Ô Here, the calculated actual capacity is the one that is obtained when all indoor units are in operation at the
same time.
7) When indoor unit is reselected as it fails to satisfy the required load
➊ In this example, indoor units at the zone A, D, E, F fails to meet the load.
❷ If DVM designer is to replace these units with indoor unit of a larger capacity, return to 5-2-2 to repeat the process.
8) Draw piping, power and communication wiring design diagrams
Ô Upon completion of indoor and outdoor unit selection, draw piping, power and communication wiring design
diagrams for installation
➊ Piping
- Get the piping lengths per each size
- Secure the model names and quantities number of subsidiary materials for piping
- Obtain drain piping specifications
❷ Power
- Get the volumes of MCCB, ELB according to product power supply
- Understand power line specification & its length
❸ Communication
- Understand communication line specification & its length
❹ Others
- For further information, refer to the installation manual.
9) Select DVM control system
Ô Select DVM control system for the last time.
Zone A B C D E F G
Total cooling load (kW) 3.3 6.3 4.5 7.1 10.4 7.0 10.0
Sensible heat load of
cooling (kW)
2.2 5.0 3.0 4.9 8.0 5.1 7.0
Indoor unit type Vivace Slim duct Mini 4way 4way Slim duct Ceiling 4way
Determined model
AVXWVH036 AVXDSH071 AVXCMH056 AVXC4H071 AVXDSH112 AVXTFH071 AVXC4H112
Indoor unit capacity (kW) 3.6 7.1 5.6 7.1 11.2 7.1 11.2
Actual capacity of
indoor unit (kW)
3.23 6.38 5.03 6.38 10.06 6.38 10.06
