Samsung DVM PLUS III - Page 422

Outdoor Units
III-240
1
1
DVM PLUS III, DVM PLUS III HR
1-3. Capacity correction
3) 12HP
Cooling
Heating
-40
-30
-20
-10
0
10
20
30
40
50
0 10 20 30 40 50 60 70 80 90 100 90 100 110 120 130 140 150 160 170 180 190 200
100%
99%
97% 95.7%
96%
98.8% 98% 96%
98%
97% 95% 94.5%
Pipe length(m)
Main pipe
size-up
Level difference(m)
-40
-30
-20
-10
0
10
20
30
40
50
0 10 20 30 40 50 60 70 80 90 100 90 100 110 120 130 140 150 160 170 180 190 200
100 %
95% 91.7% 97.7% 95 % 89 %90%
Pipe length(m)
Main pipe
size-up
Level difference(m)
