IV-13
A
CCESSORIES
2-5. Outdoor joints
1) Models
Model name Total indoor unit’s capacities
MXJ-T3100✳ Below 48 HP
MXJ-T3800✳ Above 50 HP
HR Only (For High pressure gas pipe connection)
Reducer
1 2 3 4
6
5
2) Dimensional drawing
High pressure gas
Outdoor joint
MXJ-T3100
✳
High pressure gas
MXJ-T3800 ✳
x 1 EA
6
x 1 EA
5
x 1 EA
4
x 1 EA
3
x 1 EA
2
x 1 EA
1
