Centralized controller
Function controller
Power supply
9VDC~12VDC
100mA
4) Connection with centralized controller
5) Option & Rotary switch
6) Initial LCD display
Power ON ON button press during
tracking process
Address setting switch
Dip switch – No function
DIP SW
No
Function
OFF ON
1 Cooling Cooling and Heating
2 No function No function
3ºC ºF
4 No function No function
• Temperature setting 24
ºC
• Auto mode
• Stop fan direction
• Auto airflow speed
