Control Systems
V-124
3
3
Integrated management system
➊
Indoor unit status
• Able to see the operation status of selected indoor units and indoor temperature for the present
and the past.
• Able to refer to the operation status for the last two days. If the reference day is out of range, an error
message window will appear.
❷
Power consumption of indoor units
• Displays the use time and power consumption ratios for the indoor units connected to each DMS.
3-2. S-NET3 (MST-P3P)
Select indoor unit.
Hourly indoor unit operation and
temperature display.
Use time and power consumption
ratio display.
Period reference
Display errors if the wrong period
has been set.
Statistics and analysis
DMS selection
