II-35
I
NDOOR
U
NITS
1) Cooling air velocity distribution
Floor distance
Ceiling heigt
3 m
1 m
2.5 m
1.5 m 0 m 1.5m
2.5 m
2
m
0.4m/s
0.6m/s
0.8m/s0.8m/s
0.4m/s
0.2m/s
0.6m/s
0.2m/s
◆ Discharge angle : 37°
Floor distance
Ceiling heigt
3 m
1 m
2.5 m
1.5 m 0 m 1.5m
2.5 m
2
m
25
2424
23
20
25
23
20
24
◆ Discharge angle : 37°
2) Cooling temperature distribution
Floor distance
Ceiling heigt
3 m
1 m
2.5 m
1.5 m 0 m 1.5m
2.5 m
2
m
0.8m/s
0.6m/s 0.6m/s
0.2m/s
0.4m/s
0.8m/s
◆ Discharge angle : 49°
3) Heating air velocity distribution
Floor distance
Ceiling heigt
3 m
1 m
2.5 m
1.5 m 0 m 1.5m
2.5 m
2
m
21
23
25
27
27
29
31
31
29
◆ Discharge angle : 49°
4) Heating temperature distribution
AVXCMH060E✴
