Samsung DVM PLUS III User Manual

II-39
I
NDOOR
U
NITS
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27°C DB, 19°C WB
- Outdoor temperature : 35°C DB, 24°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20°C DB, 15°C WB
- Outdoor temperature : 7°C DB, 6°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
4-2. Specifications
1) Technical specifications
AVXC4H045E✴
1/220~240/50
Heat Pump
4.5
15,300
5.0
17,000
2.23
40
0.19
34 / 29
Turbo Fan
SIC-67FV-F135-1
BLDC
14.5
16.5
R410A
EEV
Micom&Thermistors
Fuse
043217-1900C8-200000-300000
6.35
12.70
VP25 (OD 32,ID 25)
25.0
31.0
840x218x840
926x280x926
P4SMA
7.0
10.3
950x35x950
1,042x103x1,042
O
O
O
O
O
O
X
O
O
Filter / Safety Grille
24, 750
MR-BH01
MWR-SH00
MWR-TH01
MWR-WS00
MIM-B14
AVXC4H056E✴
1/220~240/50
Heat Pump
5.6
19,100
6.3
21,400
2.71
40
0.19
34 / 29
Turbo Fan
SIC-67FV-F135-1
BLDC
14.5
16.5
R410A
EEV
Micom&Thermistors
Fuse
043217-1B00C8-200000-300000
6.35
12.70
VP25 (OD 32,ID 25)
25.0
31.0
840x218x840
926x280x926
P4SMA
7.0
10.3
950x35x950
1,042x103x1,042
O
O
O
O
O
O
X
O
O
Filter / Safety Grille
24, 750
MR-BH01
MWR-SH00
MWR-TH01
MWR-WS00
MIM-B14
AVXC4H071E✴
1/220~240/50
HP / HR
7.1
24,200
8.0
27,200
3.51
45
0.21
36 / 30
Turbo Fan
SIC-67FV-F135-1
BLDC
17.0
18.5
R410A
EEV
Micom&Thermistors
Fuse
043217-1D00F9-200000-300000
9.52
15.88
VP25 (OD 32,ID 25)
25.0
31.0
840x218x840
926x280x926
P4SMA
7.0
10.3
950x35x950
1,042x103x1,042
O
O
O
O
O
O
X
O
O
Filter / Safety Grille
24, 750
MR-BH01
MWR-SH00
MWR-TH01
MWR-WS00
MIM-B14
AVXC4H090E✴
1/220~240/50
HP / HR
9.0
30,700
10.0
34,100
4.46
50
0.23
39 / 32
Turbo Fan
SIC-67FV-F135-1
BLDC
19.5
21.5
R410A
EEV
Micom&Thermistors
Fuse
043A17-11022A-200000-300000
9.52
15.88
VP25 (OD 32,ID 25)
25.0
31.0
840x218x840
926x280x926
P4SMA
7.0
10.3
950x35x950
1,042x103x1,042
O
O
O
O
O
O
X
O
O
Filter / Safety Grille
24, 750
MR-BH01
MWR-SH00
MWR-TH01
MWR-WS00
MIM-B14
ø/V/Hz
kW
Btu/h
kW
Btu/h
Liters/h
W
A
dB(A)
-
-
-
W
m
3
/min
m
3
/min
-
-
-
-
-
ø, mm
ø, mm
ø, mm
kg
kg
mm
mm
-
kg
kg
mm
mm
-
-
-
-
-
-
-
-
-
-
l/h,mm
-
-
-
-
-
Model
Power Supply
Mode*
1)
Performance
Power
Sound Level
Fan
Airflow Rate
Refrigerant
Piping
Connections
Weight
Dimensions
Panel Size
Functions
Standard
Accessories
Optional
Accessories
Temperature Control
Safety Devices
Option Code
Capacity
Motor
External Contact Interface Module
Wired Remote
Controller
Condensate (with High fan speed)
Input
Running Current
Sound Pressure (High/Low)*
4)
Type
Cooling (High)
Heating (High)
Type
Control Method
Liquid (Flare)
Gas (Flare)
Drain (Quick Lock)
Net Weight
Shipping Weight
Net Dimensions (W x H x D)
Shipping Dimensions (W x H x D)
Model
Net Weight
Shipping Weight
Net Dimensions (W x H x D)
Shipping Dimensions (W x H x D)
Auto Restart
Auto Swing
Group/Individual Control
External Contact Control
Trouble Shooting by LED
Installation Manual
Operation Manual
Pattern Sheet for Installation
Flexible Drain Hose
Filter / Safety Grille
Drain Pump (Pumping speed, lift)
Wireless Remote Controller
Cooling*
2)
Model
Type
Output
Simplified
Standard
Premium
Heating*
3)
