S&C TripSaver II User Manual

S&C Instruction Sheet 461-504 123
Appendix A
List of Available Curves
Cooper Microprocessor Form 4,5,6,FX
Inverse Segment Definition
S&C 101 Cooper 101
S&C 102 Cooper 102
S&C 103 Cooper 103
S&C 104 Cooper 104
S&C 105 Cooper 105
S&C 106 Cooper 106
S&C 107 Cooper 107
S&C 111 Coo per 111
S&C 112 Coo per 112
S&C 113 Coo per 113
S&C 115 Coo per 115
S&C 116 Coo per 116
S&C 117 Coo per 117
S&C 118 Coo per 118
S&C 119 Coo per 119
S&C 120 Cooper 120
S&C 132 Cooper 132
S&C 133 Cooper 133
S&C 134 Cooper 134
S&C 135 Cooper 135
S&C 137 Cooper 137
S&C 138 Cooper 138
S&C 142 Cooper 142
S&C 151 Cooper 151
S&C 161 Cooper 161
S&C 162 Cooper 162
S&C 163 Cooper 163
S&C 165 Cooper 165
S&C 201 Cooper 201
S&C 202 Cooper 202
SEL 351R/651R Recloser Control
Inverse Segment Definition
SEL U1 SEL U1 Moderately Inverse
SEL U2 SEL U2 Inverse
SEL U3 SEL U3 Very Inverse
SEL U4 SEL U4 Extremely Inverse
SEL U5 SEL U5 Short-Time Inverse
SEL C1 SEL C1 Standard Inverse
SEL C2 SEL C2 Very Inverse
SEL C3 SEL C3 Extremely Inverse
SEL C4 SEL C4 Long-Time Inverse
SEL C5 SEL C5 Short-Time Inverse
ABB DPU 2000R Recloser Control
Inverse Segment Definition
ABB INV ABB Inverse
ABB VI ABB Very Inverse
ABB EI ABB Extremely Inverse
ABB STI ABB Short-Time Inverse
ABB STEI
ABB Short-Time Extremely
Inverse
IEC Standard Curve
Inverse Segment Definition
IEC SI IEC Standard Inverse
IEC VI IEC Very Inverse
IEC EI IEC Extremely Inverse
IEEE Standard Curve
Inverse Segment Definition
IEEE EI IEEE Extremely Inverse
IEEE MI IEEE Moderately Inverse
IEEE VI IEEE Very Inverse
LIST OF CURVES CONTINUED ▶
