S&C Instruction Sheet 461-504 17
Installing the USB Transceiver and Power Supply
QR code
Figure 16. The Transceiver ID QR code.
Figure 17. The Transceiver ID shown on the first LCD scrolling screen.
Figure 18. The Transceiver ID label.
• Method 3: The Transceiver ID is also printed on the back of the yellow “DO NOT
DROP—HANDLE WITH CARE” tag attached to each TripSaver II recloser when it
leaves S&C Electric Company. See Figure 18.
