Sanyo PLC-HF15000L Service Manual

-142-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
750 RGB Video (480i) [5BNC Card]
0 Total Dots 0 - 4095 858
1 Disp Dots 0 - 4095 712
2 H Back Porch 0 - 4095 140
3 V Back Porch 0 - 4095 38
4 Disp Line 0 - 4095 486
5 Clamp Position 0 - 4095 1
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 1
9 Filed Enable 0 - 1 1
10 FLDBEG 0 - 15 0
11 FLDEND 0 - 15 9
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 140
23 (Sub) V Back Porch 0 - 4095 40
25 (Sub) Clamp Position 0 - 4095 89
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 1
29 (Sub) Filed Enable 0 - 1 1
30 (Sub) FLDBEG 0 - 15 0
31 (Sub) FLDEND 0 - 15 10
32 (Sub) PHASE 0 - 63 16
751 RGB Video (575i) [5BNC Card]
0 Total Dots 0 - 4095 868
1 Disp Dots 0 - 4095 706
2 H Back Porch 0 - 4095 158
3 V Back Porch 0 - 4095 42
4 Disp Line 0 - 4095 576
5 Clamp Position 0 - 4095 1
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 1
9 Filed Enable 0 - 1 1
10 FLDBEG 0 - 15 0
11 FLDEND 0 - 15 9
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 154
23 (Sub) V Back Porch 0 - 4095 44
25 (Sub) Clamp Position 0 - 4095 99
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 1
29 (Sub) Filed Enable 0 - 1 1
30 (Sub) FLDBEG 0 - 15 0
31 (Sub) FLDEND 0 - 15 10
32 (Sub) PHASE 0 - 63 16
752 RGB Video (480P) [5BNC Card]
0 Total Dots 0 - 4095 858
1 Disp Dots 0 - 4095 714
2 H Back Porch 0 - 4095 116
3 V Back Porch 0 - 4095 38
4 Disp Line 0 - 4095 484
5 Clamp Position 0 - 4095 1
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 2
9 Filed Enable 0 - 1 0
10 FLDBEG 0 - 15 0
11 FLDEND 0 - 15 0
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 114
23 (Sub) V Back Porch 0 - 4095 42
25 (Sub) Clamp Position 0 - 4095 84
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 2
29 (Sub) Filed Enable 0 - 1 0
30 (Sub) FLDBEG 0 - 15 0
31 (Sub) FLDEND 0 - 15 0
32 (Sub) PHASE 0 - 63 16
753 RGB Video (575P) [5BNC Card]
