Troubleshooting
Error
Error
Code
Error Infomation
(See Powe Failure Detection Tree)
Error
Code
Error Infomation
(See Powe Failure Detection Tree)
Normal 0 -
Power Failure
1000 AV, AV 1018 DC, FAN4
1001 MOTHR, MOTHER 1019 DC, FAN5
1002 MAIN, AD 1020 DC, FAN9
1003 MAIN, F FPGA 1021 DC, FAN8
1004 MAIN, TH 1022 DC, FAN7
1005 MAIN, PIC 1023 DC, FAN6
1006 RS232C, LAN 1024 ERR, PRESSURE
1007 MAIN, 25V 1025 ERR, FIL_DET
1008 MAIN, I/O 1026 ERR, FIL_MTR
1009 MAIN, S16V 1027 ERR, SHUT_MTR
1010 MAIN, S3.3V 1028 PFC. PFC1
1011 MAIN, S12V 1029 PFC. PFC2
1012 MAIN, KEYSTONE
1030 PFC. PFC3
1013 MAIN, GAMMA 1031 PFC. PFC4
1014 MAIN, S-5V 1032 ERR, IIC_DATA
1015 MAIN, S5V 1033 SLOT3,
1016 DC, FAN1 1034 SLOT4,
1017 DC, FAN2+3
Temperature Error
2000
Temperature Error detected on the Sensor (IC8811) (Arround the Intake Duct)
2001
Error of the detection (IC8811 communication error)
2101
Error of the detection (IC8851 communication error)
2200
Temperature Error detected on the Sensors (IC8811, IC8851) (Temp. error between internal and external)
Lamp Error
3000 Lamp1 fails on
3001 Lamp1 goes out
3002
Communication Error on Lamp1
3100 Lamp2 fails on
3101 Lamp2 goes out
3102 Communication Error on Lamp2
3200
Lamp3 fails on
3201
Lamp3 goes out
3202
Communication Error on Lamp3
3300 Lamp4 fails on
3301 Lamp4 goes out
3302
Communication Error on Lamp4
System Error
4000 Config Error (FPGA, AV, Mother, Ye)
4001 Config Error (FPGA SW, LVDS)
Filter Error 6000 Clogged filter
Error history log
This projector provides the error history log function. To
check the logs, you need to enter the service mode and
select Group No. "220" and Item No. "0" to "49". The error
code is displayed on the Data column. The description of
the error code is listed on the table below.
* How to enter the service mode and select the group, item
and data value, see "Service Adjustment Menu Opera-
tion".
Group
No.
Item
No.
Data
(Error Code)
91 0
1
2
3
:
:
49
✻
<- Latest Error
✻
✻
✻
:
:
✻
How to reset the error history log
1. Enter the Service Mode, and select Group No. "220" and Item No. "50".
2 The history log will be reset when the Data Value is set to "10". The value automatically returns to "0".
* How to enter the service mode and select the group, item and data value, see "Service adjustment menu operation".
To Next Page
