-9-
Maintaining the AMC unit
AMC unit
AMC unit
Filter cleaning
unit cover
Dust collects here.
We recommend avoiding dusty/smoky environments
when operating the projector. Usage in these environ-
ments may cause a poor image quality.
When using the projector under dusty or smoky condi-
tions, dust may accumulate on a lens, liquid crystal pan-
els, or optical elements inside the projector. Such condi-
tion may degrade the quality of the projected image.
When the symptoms above are noticed, contact your au-
thorized dealer or service center for proper cleaning.
3
4
5
5
Overturn the AMC unit and loosen the 2 screws that
secure the filter cleaning unit.
Loosen the 2 screws that secure the AMC unit and
pull it out.
After opening the cover of filter cleaning unit, take out
the dust bin from the filter cleaning unit, empty the
dust bin by discarding the dust into a trash bin or care-
fully sucking up the dust with a vacuum cleaner, clean
the brush and both surface of the mesh filter, place
back the dust bin, and then close the cover with the 2
screws.
Remove the dust on the projector and air vents.
Press the ON/STAND-BY button on the side control or
the STAND-BY button on the remote control, flip the
Main On/Off Switch off, and then unplug the AC power
cord from the AC outlet.
1
2
3
4
Close the dust tray
slowly and dispose
the dust.
Screws
Screws
Dust tray
Filter cleaning unit
When you suck up
the dust with a vac-
uum cleaner, use a
crevice tool.
Dust bin
6
7
Place the AMC unit back into the projector and fix it
with the 2 screws.
Plug the power cord and power on the projector.
Brush
Maintenance
Note:
• The projector will turn off for safety, when the AMC unit is
removed during the power-on.
• When using a vacuum cleaner to remove the dust on the
mesh filter, be careful as the filter tears easily.
• When the mesh filter gets dirty extremely, replace it with
new one.
Mesh filter
