Sanyo PLC-HF15000L Service Manual

-212-
KL8-HF15000L00
PACKING MATERIALS
910 285 9073 HANDLE CARTON-ML6A
610 351 9210 CARTON CASE TOP-KL8A
610 351 9203 CARTON CASE BTM-KL8A
610 353 1557 CARTON SPACER-KL8A
610 353 1625 CASE ACCESSORY-KL8A
610 353 1564 CUSHION BTM-KL8A
610 353 1601 CUSHION TOP-KL8A
610 354 6742 CUSHION CENTER-KL8A
610 352 6676 STRAP CARTON-KE3A
ACCESSORIES
OWNER’S MANUAL
910 319 5347 COLOR MANAGE INST-B-MM7A
610 351 5762 SETUP INST MANUAL-KL8A
610 351 5991 CD-ROM,OWNERS MANUAL-KL8A
945 072 1121 CD-ROM (R.C. MANAGER)
REMOTE CONTROL
645 103 7282 ASSY,REMOCON MXCB(SYANAI)
610 352 4450 RC-BATTERY LID-MXCB
AC CORD
! US 645 093 2458 CORD,POWER-2.5MK,US
! EU 645 093 2472 CORD,POWER-2.5MK,EU
! UK 645 093 2465 CORD,POWER-2.5MK,UK
MISCELLANEOUS
LESN COVER
SMALL 610 337 0224 ASSY,COVER LNS SMALL-KS3A
LARGE 610 337 0064 ASSY,COVER LNS LARGE-KS3A
W03 610 337 9906 ASSY,COVER LENS W03-KE3A
LENS ATTACHMENT
A-01 610 353 1335 COMPL,MOUNTING LNS 01-IDJJD
910 301 6659 ASSY,SPACER BF-MY8A
910 322 4276 COMPL,STPR CLAMP LNS SFT MM7A
610 342 7768 HOLDER AC CODE JP-KT5CL
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
652 002 9552 CABLE,INTERFACE VGA
MECHANICAL PARTS
CABINET PARTS
C01 610 355 0879 ASSY CAB TOP-KL8A
C01-1 610 351 8206 SPACER SHEET STAND-KL8A
C02 610 355 0893 ASSY CAB FRONT-KL8A
C02-1 610 351 4185 SPACER FRNT A ACCOUSTIC-KL8A
C03 610 350 1659 COMPL FILTER UNIT A-KL8A
C03-1 610 354 1105 ASSY CASE DST BTM FLT UNT-KL8A
C03-2 610 354 1082 ASSY SHAFT BRUSH FLT UNIT-KL8A
C03-3 610 354 1099 ASSY SHAFT GEAR FLT UNIT-KL8A
C03-4 610 351 3140 CASE DRIVE BTM FLT UNIT-KL8A
C03-5 610 351 3171 CASE DRIVE TOP A FLT UNIT-KL8A
C03-6 610 351 3188 CASE DRIVE TOP B FLT UNIT-KL8A
C03-7 610 351 3164 CASE DUST TOP FLT UNIT-KL8A
C03-8 610 351 3201 COVER BASE FLT UNIT-KL8A
C03-9 610 351 4376 COVER FPC FLT UNIT-KL8A
C03-10 610 351 3133 FILTER BASE MESH FLT UNIT-KL8A
C03-11 610 351 3065 GEAR RACK FLT UNIT-KL8A
C03-12 610 351 3126 GEAR BEVEL MTR FLT UNIT KL8A
C03-13 610 351 5533 HOLDER SW FLT UNIT-KL8A
C03-14 610 353 5845 MOUNTING PLATE L FLT UNIT-KL8A
C03-15 610 353 8051 MOUNTING PLATE R FLT UNIT-KL8A
C03-16 610 351 3034 TRAY BASE FLT UNIT-KL8A
C03-17 645 103 5578 MOTOR,DC FLT UNIT-KL8A
C03-18 645 103 5585 SWITCH,PUSH FLT UNIT-KL8A
C03-19 645 103 5554 UNIT,BASE LINK FLT-KL8A
C03-20 645 103 5561 UNIT,DRIVE LINK FLT-KL8A
C03-21 645 103 5592 FLEXIBLE FLAT CABLE
C04 610 354 6902 COMPL FILTER SERVICE-KL8A
C04-1 610 354 8531 COMPL FILTER HAF-KL8A
C04-2 610 351 4222 FILTER PLEATED STANDARD-KL8A
C05 610 349 4852 COMPL,STAND LEG-KL8A
C06 610 343 6265 BUTTON CONTROL-KH5AL
C07 610 349 4807 CABINET BOTTOM-KL8A
C08 610 336 9686 COVER PROJ LNS-KE3A
C09 610 349 4814 COVER FILTER-KL8A
C10 610 349 4838 COVER LMP L-KL8A
C11 610 349 4821 COVER PBS-KL8A
C12 610 350 5480 COVER LMP R-KL8A
C13 610 343 6296 DEC INLAY LED AV PNL-KH5AL
C14 610 350 5053 DEC INLAY LED-KL8A
C15 610 350 5060 DEC INLAY LED LMP-KL8A
C16 610 350 5077 DEC INLAY RC F-KL8A
C17 610 342 5665 DEC SHEET RC REAR-KH7AL
C18 610 355 9490 DEC SHEET AV-KL8A
C19 610 350 5039 HANDLE-KL8A
C20 610 350 8474 MOUNTING RAIL FILTER -KL8A
C21 610 350 5220 MOUNTING FILTER SOCKET-KL8A
C22 610 351 0002 MOUNTING COVER LMP-KL8A
C23 610 336 8528 NUT SPECIAL-KS3A
C24 610 345 4160 PANEL COMP A-KH5AL
C25 610 355 9582 SERVICE COMPL PANEL AV-KL8A
C26 610 350 8375 SPRING INTERLOCK-KL8A
C27 945 030 7356 BADGE,SANYO*53.5X12L53.5
CHASSIS PARTS
M01 910 311 5123 ASSY,HOLDER LNS B-MT8A
M01-1 910 303 9870 ASSY,PWB,LENS-BASE NET MT8A
M01-2 945 042 7344 ASSY,MOTOR(ML6A)
M01-3 945 057 3225 SWITCH,SENSOR X
M01-4 945 057 3232 SWITCH,SENSOR Y
M02 610 349 4913 COMPL MOUNTING SHUTTER-KL8A
M03 610 349 4869 COVER YE LCD-KL8A
M04 610 343 6814 HOLDER COVER LNS-KW7A
M05 610 350 5268 HOLDER BLST-KL8A
M06 610 350 5190 MOUNTING DUCT LMP L-KL8A
M07 610 350 5213 MOUNTING DUCT MR-KL8A
M08 610 355 5980 SERVICE MTG DCT MAIN-KL8A
M09 610 350 5244 MOUNTING DUCT BTM-KL8A
M10 610 350 5251 MOUNTING DUCT PBS-KL8A
M11 610 350 5398 MOUNTING DUCT LMP R-KL8A
M12 610 344 0354 SPACER AC BRKT-KH5AL
M13 610 350 9044 SPACER RAIL SLOT-KL8A
M14 610 350 5459 STOPPER DUCT LMP INH-KL8A
M15 610 349 4876 OPT BASE TOP-KL8A
M16 610 349 4883 OPT BASE BTM-KL8A
M17 610 355 5973 SERVICE OPTICAL LMP BTM-KL8A
M18 610 355 5966 SERVICE OPTICAL LMP TOP-KL8A
SCREWS
S01 312 070 4100 SPECIAL SCREW
S02 312 069 6702 SPECIAL SCREW(BLACK)
S03 411 221 9008 SCR BIN+IN TW 3X8
S04 411 216 7705 SCR S-TPG OVL 3X8
Key No. Part No. Description
Key No. Part No. Description
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Mechanical Parts List
