-213-
KL8-HF15000L00
Mechanical Parts List
S05 411 189 8709 SCR BIN 4X10¥
S06 412 077 6401 SPECIAL SCREW
S07 411 220 9504 SCR PAN+SW+W 8X25
S08 411 191 2603 BOLT HEX-SCT+SW+W 2.5X8
S09 411 192 7607 SCR BIN 2.5X6
S10 411 221 0906 SCR OVL 2X4
OPTICAL PARTS
TYPE-L LCD PANEL/PRISM ASSY
L01L 610 355 0626 ASSY,PNL/PSM L-KL8A
L01L-R 645 104 3467 LCD(LCX120AAL-7 R)
L01L-G 645 104 3474 LCD(LCX120ABL-8 G)
L01L-B 645 104 3481 LCD(LCX120AAL-6 B)
TYPE-R LCD PANEL/PRISM ASSY
L01R 610 355 0633 ASSY,PNL/PSM R-KL8A
L01R-R 645 104 3498 LCD(LCX120ABL-7 R)
L01R-G 645 104 3504 LCD(LCX120AAL-8 G)
L01R-B 645 104 3511 LCD(LCX120ABL-6 B)
COMMON
* Key No. L01-R1 to L01-B2 are included in the LCD Panel/Prism Assy.
L01-R1 645 103 3697 POLARIZED GLASS(OUT/R)1
L01-R2 645 104 1241 POLARIZED GLASS(OUT/R)2
L01-R3 645 103 4991 LENS,CONDENSER
L01-G1 645 104 1609 POLARIZED GLASS(OUT/G)1
L01-G2 645 104 1616 POLARIZED GLASS(OUT/G)2
L01-B1 645 103 3727 POLARIZED GLASS(OUT/B)1
L01-B2 645 103 3734 POLARIZED GLASS(OUT/B)2
L02R-R 645 103 4809 OPTICAL FILTER (ICV)
L02R-G 645 103 4793 OPTICAL FILTER (ICV)
L02R-B 645 103 4809 OPTICAL FILTER (ICV)
L02L-R 645 103 4793 OPTICAL FILTER (ICV)
L02L-G 645 103 4809 OPTICAL FILTER (ICV)
L02L-B 645 103 4793 OPTICAL FILTER (ICV)
L03-R1 645 092 9922 PREPOLARIZED GLASS(IN/G)
L03-G1 645 103 2447 POLARIZED GLASS(IN/G)2
L03-G2 645 103 6711 OPTICAL FILTER(IN/B)2
L03-B2 645 103 6711 OPTICAL FILTER(IN/B)2
L04-R1 645 103 3666 POLARIZED GLASS(IN/R)1
L04-G1 645 103 3673 POLARIZED GLASS(IN/G)1
L04-B1 645 103 3680 POLARIZED GLASS(IN/B)1
L05 945 041 2869 LENS,RELAY(IN)
L06 945 041 2876 LENS,RELAY(OUT)
L07 945 086 4705 LENS,CONDENSER(UV-FIL)
L08 645 103 4946 LENS,INTEGRATOR
L09 645 103 4953 LENS,CONDENSER(IN)
L10 645 103 4960 LENS,CONDENSER(OUT)
L11 645 103 4977 LENS,CONDENSER(G)
L12 645 103 4984 LENS,CONDENSER(R-FIL)
L13 945 047 1842 MIRROR(R)
L14 945 047 1859 MIRROR(B-COLD)
L15 645 094 3430 MIRROR(COLD)-S
L16 945 086 0387 OPTICAL FILTER
L17 945 043 8524 OPTICAL FILTER
L18 645 100 9739 OPTICAL FILTER(LC-CS)
L19 645 103 4922 PRISM(PBS)
L20 945 048 6051 DICHROIC MIRROR (Y/IA)
L21 645 103 5004 DICHROIC MIRROR (C)
* There are 2 types (Type-L or Type-R) of LCD Panel/Prism Assy. Used type
is indicated on the Prism Assy and Optical unit top. Refer to item “LCD
Panel/Prism Assy Removal” for further information.
SERVICE TOOLS
910 304 8209 ASSY,CG ADJUST LCD-MT8A
610 343 5596 CD-ROM,PJ SVC TOOL V420
610 337 6394 OPTICAL FILTER-S
Key No. Part No. Description
Key No. Part No. Description
To Next Page
