Sanyo PLC-HF15000L Service Manual

-144-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
1 Disp Dots 0 - 4095 1920
2 H Back Porch 0 - 4095 206
3 V Back Porch 0 - 4095 42
4 Disp Line 0 - 4095 1080
5 Clamp Position 0 - 4095 45
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 1
9 Filed Enable 0 - 1 1
10 FLDBEG 0 - 15 1
11 FLDEND 0 - 15 10
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 202
23 (Sub) V Back Porch 0 - 4095 40
25 (Sub) Clamp Position 0 - 4095 139
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 1
29 (Sub) Filed Enable 0 - 1 1
30 (Sub) FLDBEG 0 - 15 4
31 (Sub) FLDEND 0 - 15 11
32 (Sub) PHASE 0 - 63 16
757 RGB Video (1080i-50) [5BNC Card]
0 Total Dots 0 - 4095 2640
1 Disp Dots 0 - 4095 1920
2 H Back Porch 0 - 4095 206
3 V Back Porch 0 - 4095 42
4 Disp Line 0 - 4095 1080
5 Clamp Position 0 - 4095 45
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 1
9 Filed Enable 0 - 1 1
10 FLDBEG 0 - 15 1
11 FLDEND 0 - 15 10
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 202
23 (Sub) V Back Porch 0 - 4095 40
25 (Sub) Clamp Position 0 - 4095 139
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 1
29 (Sub) Filed Enable 0 - 1 1
30 (Sub) FLDBEG 0 - 15 4
31 (Sub) FLDEND 0 - 15 11
32 (Sub) PHASE 0 - 63 16
758 RGB Video (1035i) [5BNC Card]
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1920
2 H Back Porch 0 - 4095 206
3 V Back Porch 0 - 4095 80
4 Disp Line 0 - 4095 1034
5 Clamp Position 0 - 4095 45
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 1
9 Filed Enable 0 - 1 1
10 FLDBEG 0 - 15 1
11 FLDEND 0 - 15 10
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 202
23 (Sub) V Back Porch 0 - 4095 78
25 (Sub) Clamp Position 0 - 4095 138
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 1
29 (Sub) Filed Enable 0 - 1 1
30 (Sub) FLDBEG 0 - 15 4
31 (Sub) FLDEND 0 - 15 11
32 (Sub) PHASE 0 - 63 16
759 RGB Video (1080P-60) [5BNC Card]
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1920
