Sanyo PLC-HF15000L Service Manual

-148-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
5 Clamp Position 0 - 4095 30
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 1
9 Filed Enable 0 - 1 1
10 FLDBEG 0 - 15 1
11 FLDEND 0 - 15 10
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 144
23 (Sub) V Back Porch 0 - 4095 44
25 (Sub) Clamp Position 0 - 4095 100
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 1
29 (Sub) Filed Enable 0 - 1 1
30 (Sub) FLDBEG 0 - 15 3
31 (Sub) FLDEND 0 - 15 10
32 (Sub) PHASE 0 - 63 16
772 RGB Video (480P) [D-Sub15 Card]
0 Total Dots 0 - 4095 858
1 Disp Dots 0 - 4095 712
2 H Back Porch 0 - 4095 124
3 V Back Porch 0 - 4095 38
4 Disp Line 0 - 4095 484
5 Clamp Position 0 - 4095 1
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 2
9 Filed Enable 0 - 1 0
10 FLDBEG 0 - 15 0
11 FLDEND 0 - 15 0
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 122
23 (Sub) V Back Porch 0 - 4095 42
25 (Sub) Clamp Position 0 - 4095 85
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 2
29 (Sub) Filed Enable 0 - 1 0
30 (Sub) FLDBEG 0 - 15 0
31 (Sub) FLDEND 0 - 15 0
32 (Sub) PHASE 0 - 63 16
773 RGB Video (575P) [D-Sub15 Card]
0 Total Dots 0 - 4095 868
1 Disp Dots 0 - 4095 706
2 H Back Porch 0 - 4095 138
3 V Back Porch 0 - 4095 46
4 Disp Line 0 - 4095 576
5 Clamp Position 0 - 4095 1
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 2
9 Filed Enable 0 - 1 0
10 FLDBEG 0 - 15 0
11 FLDEND 0 - 15 0
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 136
23 (Sub) V Back Porch 0 - 4095 50
25 (Sub) Clamp Position 0 - 4095 98
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 2
29 (Sub) Filed Enable 0 - 1 0
30 (Sub) FLDBEG 0 - 15 0
31 (Sub) FLDEND 0 - 15 0
32 (Sub) PHASE 0 - 63 16
774 RGB Video (720P-60) [D-Sub15 Card]
0 Total Dots 0 - 4095 1650
1 Disp Dots 0 - 4095 1280
2 H Back Porch 0 - 4095 296
3 V Back Porch 0 - 4095 26
4 Disp Line 0 - 4095 720
5 Clamp Position 0 - 4095 110
