Sanyo PLC-HF15000L Service Manual

-150-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
8 VSBEG 0 - 15 1
9 Filed Enable 0 - 1 1
10 FLDBEG 0 - 15 1
11 FLDEND 0 - 15 10
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 226
23 (Sub) V Back Porch 0 - 4095 40
25 (Sub) Clamp Position 0 - 4095 164
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 1
29 (Sub) Filed Enable 0 - 1 1
30 (Sub) FLDBEG 0 - 15 1
31 (Sub) FLDEND 0 - 15 10
32 (Sub) PHASE 0 - 63 16
778 RGB Video (1035i) [D-Sub15 Card]
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1920
2 H Back Porch 0 - 4095 232
3 V Back Porch 0 - 4095 80
4 Disp Line 0 - 4095 1034
5 Clamp Position 0 - 4095 70
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 1
9 Filed Enable 0 - 1 1
10 FLDBEG 0 - 15 1
11 FLDEND 0 - 15 10
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 226
23 (Sub) V Back Porch 0 - 4095 78
25 (Sub) Clamp Position 0 - 4095 164
26 (Sub) Clamp Width 0 - 4095 20
28 (Sub) VSBEG 0 - 15 1
29 (Sub) Filed Enable 0 - 1 1
30 (Sub) FLDBEG 0 - 15 1
31 (Sub) FLDEND 0 - 15 10
32 (Sub) PHASE 0 - 63 16
779 RGB Video (1080P-60) [D-Sub15 Card]
0 Total Dots 0 - 4095 2200
1 Disp Dots 0 - 4095 1920
2 H Back Porch 0 - 4095 220
3 V Back Porch 0 - 4095 42
4 Disp Line 0 - 4095 1080
5 Clamp Position 0 - 4095 60
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 2
9 Filed Enable 0 - 1 0
10 FLDBEG 0 - 15 0
11 FLDEND 0 - 15 0
12 PHASE 0 - 63 16
22 (Sub) H Back Porch 0 - 4095 106
23 (Sub) V Back Porch 0 - 4095 42
25 (Sub) Clamp Position 0 - 4095 75
26 (Sub) Clamp Width 0 - 4095 5
28 (Sub) VSBEG 0 - 15 2
29 (Sub) Filed Enable 0 - 1 0
30 (Sub) FLDBEG 0 - 15 0
31 (Sub) FLDEND 0 - 15 0
32 (Sub) PHASE 0 - 63 16
780 RGB Video (1080P-50) [D-Sub15 Card]
0 Total Dots 0 - 4095 2640
1 Disp Dots 0 - 4095 1920
2 H Back Porch 0 - 4095 20
3 V Back Porch 0 - 4095 42
4 Disp Line 0 - 4095 1080
5 Clamp Position 0 - 4095 60
6 Clamp Width 0 - 4095 31
8 VSBEG 0 - 15 2
