-156-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
2 CVBS Y Level CVBS/Y Input Gain Adj. 0 - 255 210
3 CVBS C Level C Input Gain Adj. 0 - 255 140
4 Sub Hue Tint Adj. 0 - 63 32
5 HS Slice Level H Sync Slice Level 0 - 15 4
6 HS Slice Offset Offset from H Sync Slice Level 0 - 15 5
7 VS Slice Level V Sync Slice Level 0 - 15 6
8 VS Slice Offset Offset from V Sync Slice Level 0 - 15 6
9 Sampling Phase A/D Clock Phase 0 - 63 0
10 Pre Shoot Level Sub-Sharpness 0 - 15 8
11 Over Shoot Level Sub-Sharpness 0 - 15 8
12 Y Filter Y Input Filter Band 0 - 7 5
13 C Filter C Input Filter Band 0 - 7 5
14 NTSC/PAL Detect
NTSC/PAL Detect Threshold
0 : 64H/1V - PAL Det.strong
1 : 96H/1V
2 : 128H/1V
3 : 160H/1V - PAL Det.weak
*System - Effective only in Auto
0 - 3 1
2001 CXA2239 Option Board *Effective only for Equipped Optional Board
0 OUT 1 GR C/CR/R_OUT1 Output Gain (COMPONENT) 0 - 15 7
0 OUT 1 GG CV/Y/G_OUT1 Output Gain (COMPONENT) 0 - 15 7
0 OUT 1 GB C/CB/B_OUT1 Output Gain (COMPONENT) 0 - 15 7
5000
Dual-SDI Read Register
[Read Only]
*Effective only for Equipped Optional Board
0 VD STD
Specified Monitor Signal
00 : 720p/60
10 : 1080p/60 1080psf/30
11 : 1080p/30
12 : 1080i/50 1080psf/25
13 : 1080p/25
16 : 1080p/24
17 : 1080psf/24
21 : 1035i/60
22 : 480i/60
24 : 575i/50
255 : No SIGNAL
- -
1 Version Version Info. - -
2 Revision Revision Info. - -
9000 HD-Wireless [Read Only] *Effective only for Equipped Optional Board
0 MAC HW Version 0 - 65535 -
1
MAC SW Version
[Device revision Byte1]
0 - 255 -
2
MAC SW Version
[Device revision Byte2]
0 - 255 -
3
MAC SW Version
[Device revision Byte3]
0 - 255 -
4 Destination
DIP SW
0 : Not used, 1 : USA
2 : EU, 3 : Not used
4 : UK, 5~7 : Not used
8 : JPN, 9~15 : Not used
0 - 15
To Next Page
