-187-
Control Port Functions
PIN NO. NAME FUNCTION NAME FUNCTION POLARITY I/O
209 M10 FILTER_DET1 Filter Detection 1 I
181 N7 BALAST_SW1_EX Ballast 1 Switch O
180 N8 PFC_SW3_EX PFC Switch 3 (PFC1) O
178 N10 FILTER_DET2 Filter Detection 2 I
177 N11 LAN_POW_SW LAN Poser Switch O
144 P5 LAMP3_COVER_SW Lamp 3 Cover Switch (Not used) I
143 P6 LAMP1_COVER_SW Lamp 1 Cover Switch (Not used) I
142 P7 BALAST_SW2_EX Ballast 2 Switch O
141 P8 PFC_SW4_EX PFC_Switch 4 (PFC2) O
140 P9 PFC_SW1_EX PFC Switch 1 O
138 P11 FILTER+ Filter Motor Control + O
42 T5 LAMP4_COVER_SW Lamp Cover Switch 4 (Not used) I
41 T6 LAMP2_COVER_SW Lamp Cover Switch 2 (Not used) I
40 T7 BALAST_SW4_EX Ballast 4 Switch O
38 T9 PFC_SW2_EX PFC Switch 2 O
36 T11 FILTER- Filter Motor Control - O
● FPGA SW (IC5201, XC3S200A)
PIN NO. NAME FUNCTION NAME FUNCTION POLARITY I/O
180 N8 F_MOTOR_SW Filter Motor Switch O
144 P5 LIGHT_ALL_LED LED Light O
142 P7 CVBS/SCART_SWA CVBS/SCART Switch O
95 R7 CVBS/SCART_SWB CVBS/SCART Switch O
42 T5 LIGHT_POW_LED Light Power LED O
● FPGA SW (IC6201, XC3S200A)
PIN NO. NAME FUNCTION NAME FUNCTION POLARITY I/O
22 B22 4LCD_SW_NIOS 4LCD Drive Switch O
354 H17 POSITION_DET2 Shutter Position Detection 2 I
305 H18 POSITION_DET1 Shutter Position Detection 1 I
306 J18 SHUTTER_SW1 Shutter Switch 1 O
399 M16 SHUTTER_SW2 Shutter Switch 2 O
436 R14 LAMP3_RX Lamp 3 RXD I
402 R16 LAMP4_RX Lamp 4 RXD I
361 R17 LAMP4_TX_EX Lamp 4 TXD O
312 R18 LAMP1_TX Lamp 1 TXD O
404 T15 LAMP2_RX Lamp 2 RXD I
403 T16 LAMP1_RX LAMP 1 RXD I
362 T17 LAMP3_TX_EX Lamp 3 TXD O
313 T18 LAMP1_TX_EX Lamp 1 TXD O
370 U10 R/C_FRONT_PIC1 Remote Control Input Front I
369 U11 W_R/C_PIC1 Remote Control Input Wired I
324 V9 R/C_TOP_PIC1 Remote Control Input Top I
321 V12 R/C_REAR_PIC1 Remote Control Input Rear I
119 U21 PIC_HSYNC H Sync Output O
38 U22 PIC_VSYNC V Sync Output O
212 Y3 FAN_PWM Fan Control O
211 Y4 R/C_SCX Remote Control Output O
● IIC Bus DA Converter (IC5692, M62393FP)
PIN NO. NAME FUNCTION NAME FUNCTION POLARITY I/O
2 SCL SCL IIC Bus (Clock) I
3 SDA SDA IIC Bus (Data) I/O
4 A5 24VFAN1_SW ON: 255 (5V) / OFF 0 (0V) "H" On O
5 A6 24VFAN2_SW ON: 255 (5V) / OFF 0 (0V) "H" On O
6 A7 24VFAN3_SW ON: 255 (5V) / OFF 0 (0V) "H" On O
7 A8 24VFAN4_SW ON: 255 (5V) / OFF 0 (0V) "H" On O
12 A1 FAN_CONT9 0 ~ 255 = 0 ~ 5 V O
13 A2 12VFAN1_SW ON: 255 (5V) / OFF 0 (0V) "H" On O
14 A3 12VFAN2_SW ON: 255 (5V) / OFF 0 (0V) "H" On O
15 A4 12VFAN3_SW ON: 255 (5V) / OFF 0 (0V) "H" On O
● Ye & Color Management FPGA (IC3401, EP3C80F484)
