-205-
Parts Location Diagrams
KL8-HF15000L00
Polarized glass (IN) assembly
Note:
Parts for L02 differ according to type of LCD
panel/prism assembly.
L02L-G / L02R-G
L03-G2
L04-G
L02L-R / L02R-R
L03-R1
L04-R
L02L-B / L02R-B
L03-B2
L04-B
For Red
For Green
For Blue
Prism side
Prism side
Prism side
L03-G1
S09
S09
S09
