-84-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
3 SCANM 0 - 3 2
4 FRPM 0 - 3 2
5 HST_R_PC 0 - 127 7
6 HST_G_PC 0 - 127 7
7 HST_B_PC 0 - 127 7
8 HST_R_PF 0 - 127 12
9 HST_G_PF 0 - 127 12
10 HST_B_PF 0 - 127 12
11 DCK1_R_W 0 - 255 10
12 DCK1_R_F 0 - 127 24
13 DCK2_R_W 0 - 255 10
14 DCK2_R_F 0 - 127 24
15 DCK3_R_W 0 - 255 10
16 DCK3_R_F 0 - 127 0
17 DCK4_R_W 0 - 255 10
18 DCK4_R_F 0 - 127 0
19 DCK1_G_W 0 - 255 10
20 DCK1_G_F 0 - 127 24
21 DCK2_G_W 0 - 255 10
22 DCK2_G_F 0 - 127 24
23 DCK3_G_W 0 - 255 10
24 DCK3_G_F 0 - 127 0
25 DCK4_G_W 0 - 255 10
26 DCK4_G_F 0 - 127 0
27 DCK1_B_W 0 - 255 10
28 DCK1_B_F 0 - 127 24
29 DCK2_B_W 0 - 255 10
30 DCK2_B_F 0 - 127 24
31 DCK3_B_W 0 - 255 10
32 DCK3_B_F 0 - 127 0
33 DCK4_B_W 0 - 255 10
34 DCK4_B_F 0 - 127 0
35 ENB_D 0 - 255 56
36 PRGH_U 0 - 255 46
37 PRGH_D 0 - 255 76
38 PCGH_U 0 - 255 66
102 CXD3550_GAM
0 GAM_ON 0 - 1 1
103 CXD3550_LCK
0 LCK_LCKON 0 - 1 1
104 CXD3550_USC1
0 USC1_GAIN_R 0 - 1023 512
1 USC1_GAIN_G 0 - 1023 512
2 USC1_GAIN_B 0 - 1023 512
3 USC1_BRIGHT_R 0 - 8191 0
4 USC1_BRIGHT_G 0 - 8191 0
5 USC1_BRIGHT_B 0 - 8191 0
6 USC2_GAIN_R 0 - 1023 512
7 USC2_GAIN_G 0 - 1023 512
8 USC2_GAIN_B 0 - 1023 512
9 USC2_BRIGHT_R 0 - 8191 0
10 USC2_BRIGHT_G 0 - 8191 0
11 USC2_BRIGHT_B 0 - 8191 0
105 CXD3550_WEC
0 SVC_ID_WEC_ON 0 - 1 1
1 SVC_ID_WEC_RA_DWN 0 - 1 0
2 SVC_ID_WEC_GA_DWN 0 - 1 0
3 SVC_ID_WEC_BA_DWN 0 - 1 0
4 SVC_ID_WEC_RA_RGT 0 - 1 Panel-L: 0 / Panel-R: 1
5 SVC_ID_WEC_GA_RGT 0 - 1 Panel-L: 0 / Panel-R: 1
6 SVC_ID_WEC_BA_RGT 0 - 1 Panel-L: 0 / Panel-R: 1
7 SVC_ID_WEC_HA_TH4_RDAT1 0 - 255 16
8 SVC_ID_WEC_HA_TH4_RDAT2 0 - 255 11
9 SVC_ID_WEC_HA_TH4_RDAT3 0 - 255 10
10 SVC_ID_WEC_HA_TH5_RDAT1 0 - 255 28
11 SVC_ID_WEC_HA_TH5_RDAT2 0 - 255 11
To Next Page
