-86-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
25 VXT_GDATU2 0 - 255 16
26 VXT_GDATU3 0 - 255 18
27 VXT_GDATU4 0 - 255 22
28 VXT_GDATU5 0 - 255 21
29 VXT_GDATL1 0 - 255 13
30 VXT_GDATL2 0 - 255 8
31 VXT_GDATL3 0 - 255 9
32 VXT_GDATL4 0 - 255 11
33 VXT_GDATL5 0 - 255 10
34 VXT_BDATU1 0 - 255 26
35 VXT_BDATU2 0 - 255 16
36 VXT_BDATU3 0 - 255 18
37 VXT_BDATU4 0 - 255 22
38 VXT_BDATU5 0 - 255 21
39 VXT_BDATL1 0 - 255 13
40 VXT_BDATL2 0 - 255 8
41 VXT_BDATL3 0 - 255 9
42 VXT_BDATL4 0 - 255 11
43 VXT_BDATL5 0 - 255 10
44 VXT_TH_ON 0 - 15 15
45 VXT_TH1 0 - 255 24
46 VXT_TH2 0 - 255 71
47 VXT_TH3 0 - 255 183
48 VXT_TH4 0 - 255 231
107 CXD3550_SHAD
0 SHAD_ON 0 - 1 1
1 SHAD_LDAT1 0 - 255 53
2 SHAD_LDAT2 0 - 255 106
3 SHAD_LDAT3 0 - 255 160
4 SHAD_LDAT12_H 0 - 255 2
5 SHAD_LDAT12_L 0 - 255 106
6 SHAD_LDAT23_H 0 - 255 2
7 SHAD_LDAT23_L 0 - 255 94
8 SHAD_RDAT1 0 - 255 6
9 SHAD_RDAT2 0 - 255 13
10 SHAD_RDAT3 0 - 255 18
11 SHAD_GDAT1 0 - 255 6
12 SHAD_GDAT2 0 - 255 13
13 SHAD_GDAT3 0 - 255 18
14 SHAD_BDAT1 0 - 255 6
15 SHAD_BDAT2 0 - 255 13
16 SHAD_BDAT3 0 - 255 18
108 CXD3550_SYC
0 SYC_MASKON 0 - 15 15
1 SYC_VSMAX 0 - 8191 1440
109 CXD3550_FMD
0 FMD_VTFREETH2 0 - 8191 1430
1 FMD_VTLOCKTH2 0 - 8191 1425
110 CXD3550_CSC_4Lamp(1)(2)(3)(4) Color Shading Correction Threshold
0 CSC_XH 0 - 1 0
1 CSC_ON 0 - 1 1
2 CSC_R_GP1 0 - 511 319
3 CSC_R_GP2 0 - 511 274
4 CSC_R_GP3 0 - 511 256
5 CSC_R_GP4 0 - 511 222
6 CSC_R_GP5 0 - 511 203
7 CSC_R_GP6 0 - 511 191
8 CSC_R_GP7 0 - 511 175
9 CSC_R_GP8 0 - 511 144
10 CSC_R_GP9 0 - 511 0
11 CSC_R_GP10 0 - 511 0
12 CSC_R_GP11 0 - 511 0
13 CSC_R_GP12 0 - 511 0
14 CSC_G_GP1 0 - 511 298
15 CSC_G_GP2 0 - 511 260
16 CSC_G_GP3 0 - 511 245
To Next Page
