-88-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
7 CSC_R_GP6 0 - 511 193
8 CSC_R_GP7 0 - 511 179
9 CSC_R_GP8 0 - 511 153
10 CSC_R_GP9 0 - 511 0
11 CSC_R_GP10 0 - 511 0
12 CSC_R_GP11 0 - 511 0
13 CSC_R_GP12 0 - 511 0
14 CSC_G_GP1 0 - 511 295
15 CSC_G_GP2 0 - 511 259
16 CSC_G_GP3 0 - 511 244
17 CSC_G_GP4 0 - 511 215
18 CSC_G_GP5 0 - 511 197
19 CSC_G_GP6 0 - 511 185
20 CSC_G_GP7 0 - 511 170
21 CSC_G_GP8 0 - 511 138
22 CSC_G_GP9 0 - 511 0
23 CSC_G_GP10 0 - 511 0
24 CSC_G_GP11 0 - 511 0
25 CSC_G_GP12 0 - 511 0
26 CSC_B_GP1 0 - 511 288
27 CSC_B_GP2 0 - 511 255
28 CSC_B_GP3 0 - 511 240
29 CSC_B_GP4 0 - 511 211
30 CSC_B_GP5 0 - 511 194
31 CSC_B_GP6 0 - 511 183
32 CSC_B_GP7 0 - 511 167
33 CSC_B_GP8 0 - 511 137
34 CSC_B_GP9 0 - 511 0
35 CSC_B_GP10 0 - 511 0
36 CSC_B_GP11 0 - 511 0
37 CSC_B_GP12 0 - 511 0
113 CXD3550_CSC_3Lamp_(1)(2)(3) Color Shading Correction Threshold at Lamp 1, 2, 3
0 CSC_XH 0 - 1 0
1 CSC_ON 0 - 1 1
2 CSC_R_GP1 0 - 511 317
3 CSC_R_GP2 0 - 511 271
4 CSC_R_GP3 0 - 511 253
5 CSC_R_GP4 0 - 511 219
6 CSC_R_GP5 0 - 511 200
7 CSC_R_GP6 0 - 511 188
8 CSC_R_GP7 0 - 511 172
9 CSC_R_GP8 0 - 511 141
10 CSC_R_GP9 0 - 511 0
11 CSC_R_GP10 0 - 511 0
12 CSC_R_GP11 0 - 511 0
13 CSC_R_GP12 0 - 511 0
14 CSC_G_GP1 0 - 511 291
15 CSC_G_GP2 0 - 511 255
16 CSC_G_GP3 0 - 511 241
17 CSC_G_GP4 0 - 511 211
18 CSC_G_GP5 0 - 511 193
19 CSC_G_GP6 0 - 511 181
20 CSC_G_GP7 0 - 511 163
21 CSC_G_GP8 0 - 511 127
22 CSC_G_GP9 0 - 511 0
23 CSC_G_GP10 0 - 511 0
24 CSC_G_GP11 0 - 511 0
25 CSC_G_GP12 0 - 511 0
26 CSC_B_GP1 0 - 511 295
27 CSC_B_GP2 0 - 511 260
28 CSC_B_GP3 0 - 511 245
29 CSC_B_GP4 0 - 511 216
30 CSC_B_GP5 0 - 511 199
31 CSC_B_GP6 0 - 511 188
32 CSC_B_GP7 0 - 511 173
33 CSC_B_GP8 0 - 511 148
34 CSC_B_GP9 0 - 511 0
35 CSC_B_GP10 0 - 511 0
36 CSC_B_GP11 0 - 511 0
