Sanyo PLC-HF15000L Service Manual

-95-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
40 Silent Mode Offset Normal Fan 1 Min
Fan Voltage Set at Silent Normal (Min/Max) (Duty)
Subtract this value from normal value
0 - 255 4
41 Silent Mode Offset Normal Fan 1 Max 0 - 255 30
42 Silent Mode Offset Normal Fan 2 Min 0 - 255 10
43 Silent Mode Offset Normal Fan 2 Max 0 - 255 30
44 Silent Mode Offset Normal Fan 3 Min 0 - 255 0
45 Silent Mode Offset Normal Fan 3 Max 0 - 255 0
46 Silent Mode Offset Normal Fan 4 Min 0 - 255 0
47 Silent Mode Offset Normal Fan 4 Max 0 - 255 0
48 Silent Mode Offset Normal Fan 5 Min 0 - 255 0
49 Silent Mode Offset Normal Fan 5 Max 0 - 255 0
50 Silent Mode Offset Normal Fan 6 Min 0 - 255 0
51 Silent Mode Offset Normal Fan 6 Max 0 - 255 0
52 Silent Mode Offset Normal Fan 7 Min 0 - 255 0
53 Silent Mode Offset Normal Fan 7 Max 0 - 255 0
54 Silent Mode Offset Normal Fan 8 Min 0 - 255 0
55 Silent Mode Offset Normal Fan 8 Max 0 - 255 0
56 Silent Mode Offset Normal Fan 9 Min 0 - 255 0
57 Silent Mode Offset Normal Fan 9 Max 0 - 255 0
58 Silent Mode Offset Eco Fan 1 Min
Fan Voltage Set at Silent Eco (Min/Max) (Duty)
Subtract this value from normal value
0 - 255 4
59 Silent Mode Offset Eco Fan 1 Max 0 - 255 20
60 Silent Mode Offset Eco Fan 2 Min 0 - 255 6
61 Silent Mode Offset Eco Fan 2 Max 0 - 255 20
62 Silent Mode Offset Eco Fan 3 Min 0 - 255 0
63 Silent Mode Offset Eco Fan 3 Max 0 - 255 0
64 Silent Mode Offset Eco Fan 4 Min 0 - 255 0
65 Silent Mode Offset Eco Fan 4 Max 0 - 255 0
66 Silent Mode Offset Eco Fan 5 Min 0 - 255 0
67 Silent Mode Offset Eco Fan 5 Max 0 - 255 0
68 Silent Mode Offset Eco Fan 6 Min 0 - 255 0
69 Silent Mode Offset Eco Fan 6 Max 0 - 255 0
70 Silent Mode Offset Eco Fan 7 Min 0 - 255 0
71 Silent Mode Offset Eco Fan 7 Max 0 - 255 0
72 Silent Mode Offset Eco Fan 8 Min 0 - 255 0
73 Silent Mode Offset Eco Fan 8 Max 0 - 255 0
74 Silent Mode Offset Eco Fan 9 Min 0 - 255 0
75 Silent Mode Offset Eco Fan 9 Max 0 - 255 0
76 Smoke Cut Filter Fan Control Min
Temp Sensor Control Start/End Temp at Normal adapting Smoke
Cut FIlter
0 - 255 28
77 Smoke Cut Filter Fan Control Max 0 - 255 43
78
Smoke Cut Filter Offset Normal
Fan1 Min
Fan Voltage Set at Normal (Min/Max) (Duty)
Add this value from normal value
0 - 255 10
79
Smoke Cut Filter Offset Normal
Fan2 Min
0 - 255 10
80
Smoke Cut Filter Offset Normal
Fan3 Min
0 - 255 10
81
Smoke Cut Filter Offset Normal
Fan4 Min
0 - 255 11
82
Smoke Cut Filter Offset Normal
Fan5 Min
0 - 255 10
83 Smoke Cut Filter Offset Eco Fan1 Min
Fan Voltage Set at Eco (Min/Max) (Duty)
Add this value from normal value
0 - 255 12
84 Smoke Cut Filter Offset Eco Fan2 Min 0 - 255 12
85 Smoke Cut Filter Offset Eco Fan3 Min 0 - 255 12
86 Smoke Cut Filter Offset Eco Fan4 Min 0 - 255 12
87 Smoke Cut Filter Offset Eco Fan5 Min 0 - 255 12
255 Fan Start/Cooling Setting
0 Fan 1 Initial Volt
Fan Start Voltage (Duty)
0 - 255 30
1 Fan 2 Initial Volt 0 - 255 30
2 Fan 3 Initial Volt 0 - 255 30
3 Fan 4 Initial Volt 0 - 255 30
4 Fan 5 Initial Volt 0 - 255 30
5 Fan 6 Initial Volt 0 - 255 30
6 Fan 4 Initial Volt 0 - 255 30
7 Fan 5 Initial Volt 0 - 255 30
8 Fan 6 Initial Volt 0 - 255 30
9 Cooling Time Cooling Time Setting (x30 sec.) 1: 30 3: 90 15: 450 1 - 15 3
11 Temp Error Cooling Time
Cooling Time Setting When the Temp Error occurs (x30 sec.)
1: 30 3: 90 15: 450
1 - 15 3
12 OnStart Cooling Start Threshold 0 - 100 38
13 After shutdown cooling Cooling Operation after Shut Down (0: No, 1: Yes) 0 - 1 1
14 Fan6-9 Cooling Mode
Fan 6 - 9 Cooling Fan Switch
0: at Power Off , 1: Fixed below Fan Voltage
0 - 1 1

Sanyo PLC-HF15000L Specifications

General

Brightness	15000 ANSI Lumens
Resolution	1920 x 1200 (WUXGA)
Lamp Life	2000 hours
Projection Technology	3LCD
Lamp Type	UHP
Projection Size	40 - 600 inches
Input Connectors	HDMI, DVI, VGA, S-Video, Composite
Noise Level	39 dB
Contrast Ratio	2000:1
