4 Operation and Configuration
149
S84-ex/S86-ex Operator Manual
WLAN IP ADDRESS
Shows the IP address of the wireless LAN.
Note:
• This screen shows only if a wireless LAN unit is installed.
• DHCP should be enabled to acquire the WLAN IP address.
• The IP address is shown as “---.---.---.---” before it is acquired.
• The dynamic IP address will be shown after it is acquired.
• When the printer fails to acquire the IP address or DHCP is disabled,
the static IP address will be shown.
WLAN MAC ADDRESS
Shows the MAC address of the wireless LAN.
Note:
This screen shows only if a wireless LAN unit is installed.
BD ADDRESS
Shows the BD address.
INTERFACE AUTO SELECT
Shows the interface auto detection status.
Note:
• “-----” shows when the interface is not detected.
• DISABLE shows that the INTERFACE AUTO SELECT function is dis-
abled (manual setting).
• IEEE1284, RS-232C, LAN, USB, WLAN or Bluetooth shows the
detected interface.
To Next Page
