USB connector (Type A)
For connecting to optional USB memory.
Ribbon supply spindle
Media sensor adjustment knob
Used to adjust the position of the media
sensor.
Media guide
Feed lock latch
Used to open the feed roller and the media
sensor assembly.
Pressure roller release tab
Used to release the pressure plate.
Ribbon rewind spindle
Head lock lever
Used to release the print head assembly.
Ribbon roller
Print head (Consumables)
The part to print on the media. Perform regular
maintenance.
Platen roller (Consumables)
