4 Operation and Configuration
150
S84-ex/S86-ex Operator Manual
4.2.16
Test Print Mode
The flowchart shows the sequence of the setting screens for the test print mode. The table describes
each setting screen in detail.
Test print
When the
above
TEST
PRINT
MODE is
set as
FONT or
MEMORY
Press button
+
Power On
When the above TEST
PRINT MODE is set as
FACTORY or WLAN
When the above TEST
PRINT MODE is set as
CONFIGURATION,
BARCODE or HEAD CHECK
or
button
or
button
or button
* Press the , , or button to
select an item or set the value
accordingly. The active arrow icons
are shown on the screen.
* Pressing the button on each
screen will revert to the TEST
PRINT MODE menu.
button
button
WLAN shows only when a
wireless LAN unit is installed.
button
button
button
button
To Next Page
