7 Appendix
259
S84-ex/S86-ex Operator Manual
7.9
Print Speed and Media Size
The minimum media pitch size varies by the print speed setting.
Note
• The minimum media pitch size of continuous mode is different from dispenser mode. The values indicated
above are for continuous mode. The minimum media pitch size for dispenser mode is 18 mm.
• If using media smaller than the minimum size, the media will not stop at the right position, causing a print
misalignment.
• Do not send the print data with media size that is smaller than the minimum media pitch size, even when the
sensor is disabled.
Print speed (inches/sec) Minimum media pitch size (mm)
29
39
49
511
613
715
817
920
10 23
11 27
12 31
13 35
14 40
15 44
16 50
