SATO S84 - Ribbon Saver Timing Charts

7 Appendix
261
S84-ex/S86-ex Operator Manual
7.10.2 Ribbon Saver Timing Charts
Dispenser mode, backfeed after print and pulse input
• Normally the print head is in the down position during backfeed. However, the print head will be lifted
up when the ribbon print position is not identified.
Dispenser mode, backfeed before print and pulse input
• Normally the print head is in the down position during backfeed. However, the print head will be lifted
up when the ribbon print position is not identified.
Power ON
500 ms
20 ms
Backfeed Backfeed
Print 1st label Print 2nd label
Print head in
the up position
Label feed
External signal
PREND(TYPE1)
Operation
PRIN
Print head in
the up position
100 ms
Power ON
Label feed
External signal
UP Ribbon saver UP Ribbon saver
20 ms
PREND
(TYPE1)
Backfeed Backfeed
Print 1st label
Print 2nd label
Operation
