2 Installing the Printer
31
S84-ex/S86-ex Operator Manual
2.5.4
Interface Combination
The interface combinations that can be used for the data port and the sub port are as follows.
[o: configurable, x: not configurable]
Note
• The optional Bluetooth and optional wireless LAN are available when you have installed them.
• Do not select the same interface for the data port and sub port.
• When you have installed the optional wireless LAN, you cannot use the USB interface. The optional
wireless LAN is connected to the printer through the USB.
• The sub port cannot be used when you have set ENABLE in the INTERFACE AUTO SELECT screen.
• When WLAN is configured for the data port or the sub port, but the printer is powered on without the
wireless LAN adapter, the configured interface setting is changed from WLAN to USB. When USB is
configured as the data port or the sub port, but the wireless LAN adapter is connected, the configured
interface setting is changed from USB to WLAN.
Data Port
USB LAN RS-232C IEEE1284 Bluetooth WLAN
Sub Port
USB xoooox
LAN o
xoooo
RS-232C o o
xooo
IEEE1284 o o o
xoo
Bluetooth o o o o
xo
WLAN x o o o o
x
NONEoooooo
To Next Page
