7 Appendix
281
S84-ex/S86-ex Operator Manual
7.12.5 External Signal Interface (EXT)
This interface is designed to connect the printer with other peripherals.
Wiring chart of the 14 pins conversion cable
Basic Specifications
Connector DB 25 pins, female
Supplied with 14 pins conversion cable (Amphenol 14 pins, female)
Signal Levels High-level: +4.2 to +5.0 V
Low-level: +0.0 to +0.7 V
113
1425
DB 25 pins, female
connector (printer)
25 pins 14 pins
114
44
56
69
87
12
13
24
1213
14
2
15
16 3
17 1
18 10
20 5
21 11
SHELL SHELLSHIELD
Amphenol 14 pins,
female connector
DB 25 pins, male
connector
