SATO S84 - Hex Dump Mode; Test Print Mode

7 Appendix
227
S84-ex/S86-ex Operator Manual
7.1.6 Hex Dump Mode
7.1.7 Test Print Mode
LABEL SIZE ADJ WIDTH: S84-ex 8 dots/mm: 0832
12 dots/mm: 1248
24 dots/mm: 2496
S86-ex 8 dots/mm: 1340
12 dots/mm: 2010
Yes Yes
LABEL SIZE ADJ HEIGHT: S84-ex 8 dots/mm: 20000
12 dots/mm: 18000
24 dots/mm: 9600
S86-ex 8 dots/mm: 9992
12 dots/mm: 14988
No No
LCD POWER SAVING 00 MIN Yes Yes
LED INDICATION ON Yes Yes
ERROR INDICATION NONE Yes Yes
Setting Item Initial Value
Default
(User)
Default
(Shipping)
SELECT DUMP DATA RECEIVE DATA - -
HEX DUMP NORMAL - -
Setting Item Initial Value
Default
(User)
Default
(Shipping)
TEST PRINT MODE CONFIGURATION - -
TEST PRINT SIZE S84-ex: 10 cm
S86-ex: 16 cm
(When CONFIGURATION, BARCODE,
HEAD CHECK is selected)
--
LARGE
(When FACTORY, WLAN is selected)
--
PITCH POSITION Varied No No
OFFSET POSITION Varied No No
DARKNESS 50 Yes No
Setting Item Initial Value
Default
(User)
Default
(Shipping)
