4 Operation and Configuration
152
S84-ex/S86-ex Operator Manual
PITCH POSITION/OFFSET POSITION/DARKNESS
Adjust the print position, offset position and print darkness.
The setting range for both PITCH POSITION and OFFSET POSITION is
±3.75 mm (±0.15”) and is adjustable by 0.25 mm (0.01”).
The setting range for DARKNESS is from 00 to 99.
Note:
Press the ENTER button to start the test print.
TEST PRINT PRESS ENTER KEY
The test print is in progress.
Press the ENTER button while printing to pause the test print
operation. Press the ENTER button again to continue.
To Next Page
