4
Operation a
nd Configuration
80
S84-ex/S86-ex Operator
Manual
BCC CHECK
Set the BCC check function.
•
ENABLE
: Enable the BCC check functio
n.
•
DISABLE
: Disable the BCC check function.
Note
Shows only when PROTOCOL is set to ST
A
TUS5.
