Hardware manual for PCD3 series │ Document 26-789 ENG19│ 2018-06-29
CPU processor units
Conguration
7-2
7
7.1 CPU processor units
The commissioning of the PCD-CPU is described in 26-732 PG5 User Manual,
whichisincludedinthePG5softwarepackageasaPDFle.
Manual
User manual PG5.
Document 26-732 / Version ENG12 / 21.08.2018
After the standard installation of the PG5 package on the local computer, the
manuals are usually found in four languages under the following directory path
c:\Program Files (x86)\SBC\PG5 Version\Manuals\
The shortest route is via PG5 itself.
Programmstart PG5 -> Help -> PG5 User Manual
