General technical data
PCD3.Mxxx0 Classic CPU and expansion enclosure
3-5
3
Electromagnetic compatibility
Electrostatic discharge according to EN61000-4-2: 8 kV: Contact discharge
according to EN61000-4-3: Field strength 10V/m, 80...1000 MHz
Fast transients (burst) according to EN61000-4-4:
4 kV on DC supply lines,
4 kV on I/O signal lines,
1 kV on interface lines
Interference emission according to EN61000-4-6:
Limit class A (for industrial environment).
A guide to the correct use of these controls in the residential or living area is
available at www.sbc-support.com
(additional measures)
Immunity according to EN61000-6-4
Mechanics and assembly
Housing material Module holders: PC/ABS, light grey, RAL7035
I/O-module: PC, transparent blue
Rest Hinge: PAM, orange, RAL2003
Light guide: PC, crystal clear
Mounting rail DIN rail according to DIN EN60715 TH35
(formerly DIN EN50022) (1 × 35mm)
Connections
Terminal
blocks
Spring-clamp
10-pin, 4-pin
Screw clamps
10-pin
Spring-clamp
14-pin, 12-
pin, 8-pin
Spring-clamp
24-pin, 6-pin
Ground
terminal
1-pin
Spring
terminal
2-pin power
supply
Cross-section
solid
0.5…2.5 mm²
0.5…2.5 mm²
0.5…2.5 mm²
0.5…2.5 mm²
0.5…1.5 mm²
0.5…1.5 mm²
0.5…1.0 mm²
0.5…1.0 mm²
0.08…2.5 mm²
0.5…1.5 mm²
The terminal blocks may only be inserted 20 times. After that they have to be replaced to
guarantee a reliable contact.
Stripping
length
7 mm 7 mm 7 mm 7 mm 5…6 mm 7 mm
Standards/approvals
EN/IEC EN / IEC61131-2
Programmable logic controllers
Shipbuilding ABS, BV, DNV, GL, LRS, PRS.
Veify at www.sbc-support.com, whether the selected product is listed in the
list of relevant test centers.
cULus-listed
Veify at www.sbc-support.com, whether the selected product already has a
relevantcerticate.
TheconditionforcULusapprovalislistedontheproductyerorcanbe
downloaded from www.sbc-support.com.
