Extension with PCD3 components
PCD3.Mxxx0 Classic CPU and expansion enclosure
3-14
3
Addressing
100
Saia PCD3.C
100
Saia PCD3.C
200
Saia PCD3.C
6860
ETH 2.1 ETH 2.2
Ethernet 2
USB
Saia PCD3.M
100
Saia PCD3.C
100
Saia PCD3.C
Extension cable
PCD3.K106
Further series up to max. Address 1023
0 17616 1286432 48
192 368
For local expansion, the PCD3 LIOs (Local I/O) modules are used.
ForremoteexpansionviaProbusthePCD3RIOs(RemoteI/O)modulesare
used.
The maximum number of I/Os depends on the controller used.
When selecting the I/O modules, care must be taken that the internal 5 V and + V
supply are not overloaded (see chapter 3.9.2).
