Storage space on the PCD3
PCD3.Mxxx0 Classic CPU and expansion enclosure
3-49
3
Element Media Operand Operand
extension
memory
DATA
TEXT
DATABLOCK
X
DB
0 … 3999 4000 … 8191
per data block max. 383 register
(Each DB in the extension store can
hold 16383 registers)
TorunanapplicationonthisPCD3,itissucienttoloadonlytheUserProgram
Memory. Since this is RAM, the program and the contents of the texts and DBs
(aswellastheothermedias,registers,ags,etc.)maybelostifthereisno
voltage and the battery is empty or not inserted. If no battery module is present,
such data loss can also occur with a discharged supercap.
Splitting of the user backup memory
User backup memory is divided into two parts for these systems:
● Therstpartisavailablefortheuserprogrambackupandisalwayspresent.
InthePG5hardwarecongurator,thismemoryisaccordinglycalledUser
Program Backup.
● Thesecondpart,optionallycongurableinthePG5calledextensionmemory
backup (data backup), can be used to back up DBs and texts to the Flash at
runtime.
If a part of the backup memory is used as an extension memory backup, the available
user program backup memory will be reduced by twice the size of the extension memory
backup used. In parallel with the reducon of the user program backup memory, the user
program memory is also adjusted, so that the enre User Program Memory can always be
copied to the Backup Flash.
Available user backup memory on the onboard memory
ThedierentversionsofthePCD3CPUhavedierentsizeduserprogram
memories (and accordingly also user backup memories). The actually usable
memories are inherently PCD3 type dependent. As the available memory on the
PCD3 has been increased over time, there is a dependency on hardware and
rmwareversion(thelargermemoryiscongurablefromversion030).
