HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 10 of 201
Version: 25F
PAA Prozessabbild der Ausgänge (Process image of the
outputs)
PAE
Prozessabbild der Eingänge (Process image of the inputs)
PES
Programmable electronic control
Pilot duty UL Rating
Qx.y
(1)
Digital Output
T0,T1 Pulse outputs
TB(1) T bus connector (backplane bus)
PELV Protective Extra Low Voltage
PLC
Programmable Logic Controller
SD bus (on request) Serial diagnostic bus for electronic Schmersal safety
switches
SDDC (on request) Safe Device-Device Communication
SELV Safety Extra Low Voltage
SMMC (on request)
Safe Master
-
Master Communication
SRP/CS
Safety related parts of a control system
SSI
Synchronous Serial Interface
SW
Software; here: safety
-
related application software
VDE Verband der Elektrotechnik, Elektronik und
Informationstechnik e. V.
Yx.y
(1)
Auxiliary output
(1)
Module address x = 0 ….. 2
Channel address y = 0 ….. 39
3 Safety instructions
3.1 Intended use
The devices in the series PSC1-C-100 are programmable safety controllers for providing
safety shutdown and safety functions. The devices are intended for usage
- In EMERGENCY STOP systems,
- As a safety component in the context of the EC Machinery directive 2006/42/EC,
- As PES for risk reduction in the context of IEC 61508,
- In safety circuits according to IEC 60204-1 and EN 60204-32,
- As PES for functional safety in the context of IEC 62061,
- As SRP/CS in the context of EN ISO 13849,
- As a device for providing safety functions according to IEC 61800-5-2,
- As a logic unit for signal conversion and signal processing in a two-hand circuit
according to EN 574.
