10 Technical specifications
10.1 Ambient conditions
Degree of protection
IP 20
Ambient temperature
0
°C* ... 50
°C
Climatic class
3k3 according to IEC
60721
Service life
(Tm, time to mission))
20 years in 50 °C environment
10.2 Safety-related characteristic data
Max. achievable safety class
• SIL 3 as per IEC 61508
• Category 4 as per EN945-1
• Performance Level e as per EN ISO
13849
-
1
System structure 2-channel with diagnostics (1oo2) according to
IEC 61508
Architecture category 4 according to EN ISO
13849
Design of the operating mode
"High demand" as per IEC 61508
Probability of a dangerous failure per
hour (PFH value)
Specific values as per tables "Safety-
related characteristic data"
PSC1
-
C
-
100
-
x
See section
3.7.1
PSC1-E-21-SDM1
PSC1-E-22-SDM1-2
(1 axis)
See section 3.7.2
PSC1-E-23-SDM2
PSC1-E-24-SDM2-2
(2 axes)
See section 3.7.2
PSC1
-
E
-
13x
See section
3.7.2
Proof test interval (IEC 61508) 20 years, after that the module must be replaced
