4.2.2.4 Specific diagnostic measures in relation to the encoder type used
Encoder type
Supply voltage monitoring Differential level monitoring SIN/COS plausibility monitoring Input signal level monitoring Monitoring of the permissible quadrants Monitoring of the count signal separately for track A/B Monitoring of the reference signal / measured signal transmission ratio Reference signal frequency monitoring Reference signal voltage monitoring Measured signal form factor analysis Plausibility test, position signal versus speed Clk frequency monitoring
Interface X 1/2, X23
Incremental X X X
SIN/COS X X
SSI X X
Proximity switch 2 x
count input
X
Proximity switch 1 x
count input
X
Interface X 3/4
Incremental X X X X
HTL X X
Resolver X X X X X X
SIN_COS X X X
1)
SSI X X X X
Options:
(1)
Only in the high-resolution mode
(2)
in preparation
