Installation manual
HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 143 of 201
Version: 25F
Logic processing:
The following evaluation is to be undertaken in both channels:
Signal A Signal B Result
Low
Low
False
High
Low
True
Low High True
High
High
True
5.12.2.7 HTL sensor
Signal level: 24 V/0 V
Physical layer: Push/pull
Measured signal A/B: Track with 90° phase difference
Max. count pulse frequency: 200 kHz on X27/28 or X29/30
(only PSC1-E-22 or PSC1-E-24)
Diagnostics:
Diagnostics
Parameter
Fault threshold
Supply voltage monitoring Fixed values
5 V, 8 V, 10 V, 12 V, 20 V,
24 V
See section Fehler!
Verweisquelle konnte nicht
gefunden werden.
Monitoring differential level
on the input
Fixed value 24 V +/- 20% +/-2% (measuring
tolerance)
Monitoring of the count
signal separately for each
track A/B
Fixed value
D
P > 4 increments
5.12.2.8 Resolver
Measured signal: SIN/COS – track with 90° phase difference
Max. count pulse frequency: 2 kHz/pole
Resolution: 9 bits / pole
Master mode:
Reference signal frequency: 8 kHz
Slave mode:
Reference signal frequency: 6 - 16 kHz
Reference signal shape: Sine, triangle
Diagnostics:
Diagnostics
Parameter
Fault threshold
Monitoring ratio Fixed values
2:1, 3:2, 4:1
See section Fehler!
Verweisquelle konnte nicht
gefunden werden.
SIN²+COS² signal amplitude
monitoring
Fixed value <2.8 V +/- 5% (measuring
tolerance)
Monitoring of phase A/B Fixed value 90° +/- 7° +/-2° (measuring
tolerance)
