schmersal PSC1 - Terminal Assignment PSC1-E-37

Installation manual
HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 118 of 201
Version: 25F
5.7.8 Terminal assignment PSC1-E-37
1
X99
4
1
1
X11
X12
4
4
1
1
X21
X22
4
4
1
1
X13
X14
4
4
I00 I01
I02 I03
NC NC
T0 T1
I09
I10 I11
I04 I05
I06 I07
CPU
I08
1
1
X23
X24
4
4
I12 I13
Y0 Y1
Q4.1 Q4.2
Q5.1 Q5.2
Q0 Q1
Q2 Q3
REL
A1.1 A1.2 A2.1 A2.2
FB 1.1FB 1.2
COM
Terminal assignment
Unit
Terminal
Pin
Description
Note
REL
X11
1
–
A1.1
Device power supply +24 VDC
2
–
A1.2
Device power supply +24 VDC
outputs
3
–
A2.1
Device power supply 0 VDC
4
–
A2.2
X12
1
–
I 12
Safe digital inputs
2
–
I 13
3
–
Y0
Signal outputs
4
–
Y1
X21
1
–
Q0
Output pn switching Q0_PP / pp switching Q0
optionally can be configured in the
parameters via SafePLC2
2
–
Q1
Output pn switching Q1_PN / pp switching Q1
3
–
Q2
Output pn switching Q2_PP / pp switching Q2
4
–
Q2
Output pn switching Q3_PN / pp switching Q3
X22
1
–
Q4.1
Safe relay output
2
–
Q4.2
3
–
Q5.1
Safe relay output
4
–
Q5.2
CPU
X13
1
–
NC
No function
2
–
NC
3
–
T0
Pulse outputs
4
–
T1
X14
1
–
I 00
Safe digital inputs
2
–
I 01
3
–
I 02
4
–
I 03
X23
1
–
I 04
2
–
I 05
3
–
I 06
4
–
I 07
X24
1
–
I 08
2
–
I 09
3
–
I 10
4
–
I 11
X99
1
–
NC
No function
2
–
NC
3
–
NC
4 – FE Functional earth
Connect to FE or PE of the control
cabinet (use short cables)
