Terminal assignment
Unit
Terminal
Pin
Description
Note
CPU
X13
1
–
NC
No function
2
–
NC
3
–
T0
Pulse outputs
4
–
T1
X14
1
–
I 00
Safe digital inputs
2
–
I 01
3
–
I 02
4
–
I 03
X23
1
–
I 04
2
–
I 05
3
–
I 06
4
–
I 07
X24
1
–
I 08
2
–
I 09
3
–
I 10
4
–
I 11
