Diagnostics:
Diagnostics
Parameter
Fault threshold
Supply voltage monitoring Fixed values
5 V, 8 V, 10 V, 12 V, 20 V,
24 V
See section Fehler!
Verweisquelle konnte nicht
gefunden werden.
SIN²+COS² amplitude
monitoring
Fixed value 1V
pp
65% or 1 V
pp
+/- 2.5%
(measuring tolerance)
Monitoring of phase A/B Fixed value 90° +/- 30° +/-5° measuring
tolerance)
Monitoring of quadrant count
signal / signal phase
Fixed value +/- 45°
5.12.2.5 Proximity switch
Signal level: 24 V/0 V
Max. count pulse frequency: 10 kHz
Min. count pulse frequency: 4 Hz
De-bounced switching logic
Diagnostics:
Diagnostics
Parameter
Fault
threshold
Monitoring of supply voltage
not possible
- -
