12.3.8.2 Validating FUP against IL and parameters using validation report
The programming in the FUP is to be compared with the IL listing in the validation report.
Example IL listing in the validation report
Validation report
PLC program
Index Command Operand Validated
1
NO1
SLI_EN.1
2
NO1
SLI_EN.2
3 NO1 SLI_EN.3
4
NO1
SCA_EN.1
5 NO1 SCA_EN.2
6
NO1
SCA_EN.3
7
NO1
SLS_EN.2
8 NO1 SCA_EN.4
9
NO1
SLS_EN.3
10 NO1 SLS_EN.4
11
NO1
SLI_EN.5
12
SQH
13
LD
I0.00
14 ST MX.2
15
SQC
16
SQH
17
LD
I0.02
18 AND I0.03
19
ST
MX.3
20 SQC
A stepwise check is recommended. The check is all the more efficient the more the
programming in the FUP has been structured.
