3.7.5 Encoder specifications
Encoder
type
Connection Diagnostics
Value
SIN/COS; TTL
X1; X2 Max. frequency
200 kHz
X3; X4 Max. frequency
250 kHz
Amplitude SIN/COS
1 Vpp +/- 0.3 V
Type of connection
Sub-D 9-pin
SSI absolute
X1; X2
Clock frequency
Master
mode 150 kHz / slave mode max. 250 kHz
X3; X4
Clock frequency
Master mode 150 kHz / slave mode 150
-
350 kHz
Max. frame length / data length
32 / 28 bits
Pos. user data
Adjustable
Type of connection
Sub
-
D 9
-
pin
Resolver
X3; X4 Measured signal
Sin/Cos – track with 90° phase difference
Signal frequency
Max. 600 Hz (900 Hz low-pass)
Input voltage
Max. 8 Vpp (on 16 kΩ)
Resolution
9 bits / pole
Poles supported
2 - 16
Reference frequency (listener)
6 kHz
–
16 kHz
From software release 03-
00
-
00
-
01
4 kHz – 16 kHz
Reference frequency (master)
8 kHz
Reference amplitude
8 Vpp
–
28 Vpp
Reference signal shape
Sine, triangle
Transmission ratio
2:1; 3:1; 4:1
Phase error
Max. 8°
Type of connection
Sub
-
D 9
-
pin
HTL
I04
–
I07
Max. frequency
10 kHz restriction, proxy 2 only 4 kHz, see 5.12.2.5
H1A, H2A, H3A
H1B, H2B, H3B
H4A, H5A, H6A
H4B, H5B, H6B
Max. frequency
200 kHz
Type of connection
Removable screw terminal
3.8 Derating outputs
Maximum current carrying capacity based on temperature.
This "derating" must be taken into account for all 2A outputs (IO board and REL board)!
At an ambient temperature of up to 30°C the 2A outputs may be fully loaded.
From an ambient temperature of 30°C to a maximum of 50°C, the 2A outputs may only be
loaded up to a maximum of 1.8A and the total current may not exceed 10A.
