Installation manual
HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 135 of 201
Version: 25F
5.11.3.7 Connection of proximity switches
Connection is via the connector X23 to the digital inputs I04 … I07.
The exact pin assignment is dependent on which encoder type is used and is given in the
connection diagram in the programming software user interface.
Note:
On the usage of HTL encoder, it is to be noted that the tracks A+ and B+ or A- and B- must be
combined correspondingly.
