3.7.4.1 Tech. characteristic data: Optional universal communication interface
Safety
-
related characteristic data
PL according to EN ISO 13849
n.a.
PFH /
architecture
n.a.
SIL according to EN 61508
n.a.
Proof test interval
n.a.
General data
Decentral communication interfaces
2x RJ 45*
Fieldbus interfaces
-
FB1
2x RJ 45**
-
FB2
1x Sub
-
D***
Memory Card
(safety program)
1x microSD (front
side)
SD bus (on request) Connector (with screw terminals)
Status LEDs 4
Fieldbus address rotary switches
-FB2 2
Electrical data
Power consumption
(SD bus)
3.6 W
Environmental data
Temperature 0° … +50° C operating temp.;
-
25C° … +70C° storage, transport
Degree of protection
IP 20
Climatic class
3k3 according to DIN 60 721
EMC
Corresponding to EN 55011 and EN 61000
-
6
-
2
Mechanical data
Size
(HxDxW [mm])
100x115x22.5
Attachment
Can be snapped to DIN rail
Number of T
-
bus
Included in the items supplied
Min. connection cross
-
section / IL
0.2 mm² / 24
Max. connection cross
-
section / IL
2.5 mm² / 12
Options
* Optionally for SDDC or SMMC (on request)
** Available fieldbuses EtherNet/IP, PROFINET and EtherCAT
*** Available fieldbuses PROFIBUS, CANopen
