Installation manual
HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 8 of 201
Version: 25F
2.1 Reference documents
Description
Reference
Configuration of the PSC1 module
with the "SafePLC2" programming
system
Programming manual SafePLC2
Validation report on the parameter
configuration implemented and the
PLC program
Safety-related test with acceptance
report
Acceptance for general safety-related
applications
Certificate on the type test for safety
control according to Machinery directive
2006/42/EC for product modules
PSC1-C-100
PSC1-C-100-MC
(1)
PSC1-C-100-FBx
(2)
PSC1-E-21-SDM1
PSC1-E-22-SDM1-2
PSC1-E-23-SDM2
PSC1-E-24-SDM2-2
PSC1-E-131-12DI-10DIO
PSC1-E-133-12DI-6DIO-4RO
PSC1-E-37-14DI-4DO-2RO-RIO
Options:
(1)
Memory Card to store the configuration, the program and the data; see under:
(2)
For version see: “Optional universal communication interface"
Note:
• Read this manual carefully before you start the installation and commissioning of the
PSC1 modules.
• Observing the documentation is a requirement for fault-free operation and the
acceptance of claims under warranty.
